Poynting OMNI-493 617-6000 MHz, 9dBi Omni-Directional, Marine & Coastal 5G/LTE Antenna - N-Type

The OMNI-493 is an ultra-wideband, high performance, omni-directional antenna that covers the contemporary 4G/LTE and future 5G operating frequencies with excellent balanced gain across all frequencies. The ultra-wideband performance from the antenna allows it to operate from 617 to 6000 MHz, with a peak gain of 8 dBi. This makes the antenna usable in all parts of the world and guarantees signal reception almost everywhere. The antenna design allows for superior pattern control over the entire frequency range, making the OMNI-493 a true high performance omni-directional antenna, suitable for marine and coastal applications. Poynting antennas achieves this performance through new antenna design, where multiple dipoles and a unique (patented) feed network is implemented. The antenna is future proof as it covers the up and coming 617 to 698 MHz band, as well as 3400 to 3800 MHz which will be utilized for future 5G applications.

• Ultra-Wideband Frequency Coverage: Operates from 617 to 6000 MHz, supporting 4G/LTE and future 5G networks.
• Includes band 71 (617 to 698 MHz) and 3.5 GHz 5G bands
• Frequency Range & Gain; 4 dBi @ 617 – 960 MHz / 7 dBi @ 1427 – 1517 MHz / 8 dBi @ 1710 – 2700 MHz / 6.8 dBi @ 3400 - 4200 MHz / 6.5 dBi @ 5000 - 6000 MHz
• Wi-Fi Standard: Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
• LTE Port: 1
• Mounting Type: Standard 1'' -14 TPI marine mount & Wall/pole mount
• Connectors: N-Type
• IP68, Marine Grade, Salt Spray Protected
• 3 year warranty
• Product Box Contents A-OMNI-0493, 1” (14 TPI) Marine Adapter (BRKT-40) & L-bracket (Ø30-50mm Pole)
